Product Details
＋
| Product Attribute | Attribute Value |
|---|---|
| Approvals | cUL Recognized;UL Recognized |
| Cable Type | PVC |
| Contact Configuration | AC: L1 switched, DC: NPN open collector |
| Contact Rating | 300 mA AC/DC at 20-264 Vac/15-30 Vdc |
| Cord Length | 79.2 Foot |
| Height | .71 Inch |
| Input Voltage | 20-264 Vac 50/60 Hz, 15-30 Vdc (NPN) |
| IP Rating | IP69K |
| Length | 2.6 Inch |
| NEMA Rating | NEMA 1 ; NEMA 2 ; NEMA 3 ; NEMA 4 ; NEMA 4X ; NEMA 6 ; NEMA 12 ; NEMA 13 |
| Output | NPN |
| Protection | Latching S/C |
| Sensing Mode | Diffuse |
| Sensor Type | Back Ground Suppression |
| Series | |
| Type | Reflective Sensors |
| UPC Code | 782113823294 |
| Width | .47 Inch |
Overview
Eaton Comet Series Sensors
The comet series of high performance, 18mm tubular sensors by Eaton have been designed in a variety of models and modes to solve virtually any sensing problem. The sensors are available in thru-beam, reflex, polarized reflex, diffuse reflective, focused diffuse reflective, wide angle diffuse reflective, perfect prox and plastic fiber optic sensing.
